Deep Blue 40i 1400
For commercial operators and green boaters





Deep Blue 40i 1400

For commercial operators and green boaters

$ 23,999.00
plus shipping charges

Power
40 HP
80 HP



Product description


  • Inboard system with power electronics and 1400 rpm for displacement sailing
  • A synthesis of performance and a perfectly integrated overall system with a ground-breaking safety concept that sets Deep Blue apart from all other electric drive systems on the market
  • All the components of the system are perfectly engineered to match each other and are completely waterproof
  • We provide a 9-year warranty on the Deep Blue's battery capacity
  • Electric boat propulsion is not only powerful and safe, it is also a genuine commercial alternative for heavy users
  • Including on-board computer with 5.7" touchscreen display
  • Special group tariff from Pantaenius Yacht Insurance with improved insurance protection and lower premiums compared with the normal tariff for boats with other high-voltage drives
  • Transparent maintenance overhead An electric drive system requires far less maintenance than comparable drive systems using fossil fuel


Ordering information


  • Item number: 3304-00  | EAN: 4260113693469
  • Equipment included: Inboard drive system (33 kW peak output, 40 HP equivalent or 66 kW peak output, 80 HP equivalent) consisting of motor including motor electronics, homokinetic joint , cooling pump, connection box, charger, remote throttle, on-board computer with display, cables, 1400 rpm motor speed (high-voltage batteries, shaft and propeller not included)
  • Warranty: 2 years on the system for non-commercial use; 9-year warranty on the battery
  • We currently deliver to the following countries








  • Deep Blue i 1400 rpm

    Torqeedo Deep Blue i 1400 inboard motor Torqeedo Deep Blue i 1400 inboard motor

    It is not just power and performance that make Deep Blue the first of its kind. It is unparalleled performance combined with full system integration and groundbreaking safety levels that set Deep Blue apart from all other electric propulsion systems on the market.

    All the components of the system are perfectly engineered to match each other and are completely waterproof. State-of-the art monitoring technology with pilot lines and insulation monitors safeguard the high-voltage system against the risk of short circuits. The same high-performance lithium batteries used to power cars also power Deep Blue – after we developed them further for use in boats. These and many more safety and performance features make Deep Blue a unique high-voltage propulsion system for electric boats.

    And if that's not enough – we provide a 9-year warranty on the Deep Blue's battery capacity, that's right, 9 years. Electric boat propulsion is not only powerful and safe, it is also a genuine commercial alternative for heavy users in particular. Whether the 40 HP or 80 HP version – switch to full electric power!


    Deep Blue i 1400 rpm – Benefits:

    • Deep Blue: the first high-power propulsion system in serial production. A fully integrated system in which all components are designed to match each other seamlessly and to work together perfectly on the water. An overall concept that is unique in terms of safety, performance and range.
    • The Deep Blue i 1400 rpm is the "planer" at your side.
    • Available as 40 HP or 80 HP equivalent depending on requirements.
    • 9-year warranty on battery bank:
      a reliable battery lifespan is key for electric boating economics. That is why the Deep Blue battery comes with a long-term battery capacity warranty: 9 years after commissioning, the batteries will still have 80 % of their original capacity, even if you use them every day.* Battery ageing is transparent and can be tracked by the user in the on-board computer at any time.
      * Adherence to warranty conditions required. See Deep Blue battery capacity warranty at www.torqeedo.com for more details.
    • Low-maintenance system: switching makes sense from as little as EUR 4,600 in annual fuel costs – contact us for more information.
    Torqeedo Deep Blue i 1400 inboard motor
    HV DC Power (345V)
    LV DC Power (12V / 24V)
    AC Power (100 – 240V)
    Data Lines (CAN, Ethernet)

    High-voltage electric motor:
    available for shaft drive, saildrive or outboard; 98% motor efficiency
    Connection box:
    this is where all electrical and signal cables come together.
    Top-class high-voltage battery:
    from the automotive industry. 9-year warranty on 80% of original battery capacity.
    12 V battery:
    activates the high-voltage battery at each start-up.
    Charger:
    charges the high-voltage battery/batteries from onshore power
    Onshore power connection
    Electronic remote throttle:
    for operating the electric motors and other system functions
    On-board computer with touchscreen:
    waterproof with 5.7-inch display, 14 different application views.




  • Range

    Deep Blue 80i with Two High-voltage Batteries



    Speed in km/h (knots)* Range in km (nm)* Running time in hours: minutes
    Slow 7.5 (4.0) 40-120 (22-65) 05:20 - 16:00
    Full throttle 36-54 (19-29) 18-27 (10-15) 00:30

    Deep Blue 40i with One Battery



    Speed in km/h (knots)* Range in km (nm)* Running time in hours: minutes
    Slow 7.5 (4.0) 37-60 (20-32) 05:00 - 08:00
    Full throttle 32-44 (17-24) 16-22 (9-12) 00:30

    * Depends on type of boat, load, propeller and conditions. Speed and range indications do not represent a legal guarantee.

    Information on range and speed

    For a displacement boat making way through the water, the required propulsive power increases in proportion to the cube of the speed. This means that if you want to double your speed, you need eight times as much power.

    And vice-versa, a small reduction in speed is enough to increase the achievable range substantially.

    The Torqeedo Deep Blue's on-board computer calculates the remaining range constantly, by linking the motor's consumption data with the charging level of the batteries, and the speed over the ground from the GPS. This allows you to read the remaining range in real time from the motor display or the smartphone app TorqTrac.





  • Specifications

    Technical Data Deep Blue

    Deep Blue system Deep Blue i 1400 rpm Deep Blue i 1400 rpm
    40 HP 80 HP
    Input power (peak) in kW 33 66
    Input power (continuous) in kW 25 50
    Propulsive power in kW > 16.2 > 32.4
    Comparable petrol outboard (shaft power) 40 HP 80 HP
    Maximum overall efficiency in % > 54 > 54
    Integrated battery: usable energy in kWh 12.8 25.6 - 51.2
    Nominal voltage 345 345
    Final charging voltage 389 389
    Motor weight without battery, including electronics in kg 80 80
    Weight of 1 battery in kg 149 149
    Total system weight example in kg
    (long shaft version, 1 charger, including connection box, display, throttle and cabling)
    254
    (with 1 battery)
    410
    (with 2 batteries)
    Shaft length - -
    Standard propeller - -
    Maximum propeller speed in rpm at fill load 1,400 1,400
    Control - -
    Tilting device - -
    Trim device - -
    Integrated on-board computer with touchscreen display yes yes


    Technical Drawing













  • Tips

    Deep Blue i 1400 FAQ

    • What versions are available?

      Outboard: outboard with remote steering and throttle, available as 40- or 80-HP equivalents, various shaft lengths. Models: Deep Blue 40 RL / RXL and Deep Blue 80 RL / RXL.


      Outboard with tiller: outboard with tiller for steering and throttle, available as 40- or 80-HP equivalents, various shaft lengths. Models: Deep Blue 40 TL / TXL and Deep Blue 80 TL / TXL.


      Inboard: inboard with drive shaft, available as 40- or 80-HP equivalents, various motor speeds. Models: Deep Blue 40 i 1400 / 1800 and Deep Blue 80 i 1400 / 1800.

      Sail Drive: sail drive with remote throttle, available as 40 HP equivalent. Models: Deep Blue 40 SD.

    • When is it worth switching to the Deep Blue?

      Switching could make sense for you from as little as EUR 4,600 in annual fuel costs.

      Are your fuel costs higher than EUR 4,600 per year? If they are, it might be worth switching to the Deep Blue today. The Deep Blue will in any case protect you from the expected increases in fuel prices. And you will be setting an example for economic reason while showing respect for nature and demonstrating how we can retain mobility in increasingly difficult ecological conditions – more quietly, more cleanly and with greater environmental awareness.

    • What maintenance is involved?

      Transparent maintenance overhead.

      An electric drive system requires far less maintenance than comparable drive systems using fossil fuel

    • What is the warranty?

      The Deep Blue has a 2-year warranty from the date of purchase for non-commercial use.

      9-year warranty on battery bank

      A reliable battery lifespan is key for electric boating economics. That is why the Deep Blue battery comes with a long-term battery capacity warranty: 9 years after commissioning, the batteries will still have 80 % of their original capacity, even if you use them every day.* Battery ageing is transparent and can be tracked by the user in the on-board computer at any time.


      * Adherence to warranty conditions required. See Deep Blue battery capacity warranty at www.torqeedo.com www.torqeedo.com for more details.
